BPFE-ALTH 127K – fiksni točkić Blickle

Šifra 754165

BPFE-ALTH 127K

Fiksni točkić, Blickle, Made in Germany

Ukratko: BPFE-ALTH 127K je fiksni točkić Blickle promjera 125 mm, širine 54 mm, nosivosti 450 kg pri 4 km/h (statički 1125 kg). Ukupna visina je 225 mm. Cijena je 627.24 KM s PDV-om.

Heavy duty fixed castor, with polyurethane torsion spring, heavy duty wheel, with Blickle Extrathane® polyurethane tread, with aluminium wheel centre

627.24 KM

Cijena s PDV-om. Dostava širom Bosne i Hercegovine.

Veće količine: posebna ponuda na upit, +387 62 924 140, info@mhtrade.co.ba.

Tehnički podaci

Šifra artikla754165
EAN4047526112271
Promjer točka125 mm
Širina točka54 mm
Ukupna visina225 mm
Nosivost pri 4 km/h450 kg
Statička nosivost1125 kg
Veličina ploče140 x 110 mm
Razmak rupa105.0 x 80.0 mm
Offset46 mm
Ne ostavlja tragoveda

Nosač

  • solid welded steel construction, solid forged part, zinc-plated, yellow-passivated, Cr6-free
  • patented woodruff key design for outstanding spring-damping properties

Točak

  • tread: high-quality polyurethane elastomer Blickle Extrathane®, hardness 92 Shore A, colour yellow, non-marking, non-staining
  • wheel centre: die-cast aluminium, colour silver grey

Dodatne karakteristike

  • high chemical resistance to many aggressive substances
  • operating temperature: -20 °C to +70 °C, temporarily up to +90 °C, reduced load capacity over +40 °C
