Šifra 754166
BPFE-ALTH 150K
Fiksni točkić, Blickle, Made in Germany
Ukratko: BPFE-ALTH 150K je fiksni točkić Blickle promjera 150 mm, širine 50 mm, nosivosti 500 kg pri 4 km/h (statički 1250 kg). Ukupna visina je 255 mm. Cijena je 631.00 KM s PDV-om.
Heavy duty fixed castor, with polyurethane torsion spring, heavy duty wheel, with Blickle Extrathane® polyurethane tread, with aluminium wheel centre
631.00 KM
Cijena s PDV-om. Dostava širom Bosne i Hercegovine.
Veće količine: posebna ponuda na upit, +387 62 924 140, info@mhtrade.co.ba.
Tehnički podaci
| Šifra artikla | 754166 |
|---|---|
| EAN | 4047526112288 |
| Promjer točka | 150 mm |
| Širina točka | 50 mm |
| Ukupna visina | 255 mm |
| Nosivost pri 4 km/h | 500 kg |
| Statička nosivost | 1250 kg |
| Veličina ploče | 140 x 110 mm |
| Razmak rupa | 105.0 x 80.0 mm |
| Offset | 46 mm |
| Ne ostavlja tragove | da |
Nosač
- solid welded steel construction, solid forged part, zinc-plated, yellow-passivated, Cr6-free
- patented woodruff key design for outstanding spring-damping properties
Točak
- tread: high-quality polyurethane elastomer Blickle Extrathane®, hardness 92 Shore A, colour yellow, non-marking, non-staining
- wheel centre: die-cast aluminium, colour silver grey
Dodatne karakteristike
- high chemical resistance to many aggressive substances
- operating temperature: -20 °C to +70 °C, temporarily up to +90 °C, reduced load capacity over +40 °C
