BPFE-ALTH 125K-AS-FA-CO – fiksni točkić Blickle

Šifra 937371

BPFE-ALTH 125K-AS-FA-CO

Fiksni točkić, Blickle, Made in Germany

Ukratko: BPFE-ALTH 125K-AS-FA-CO je fiksni točkić Blickle promjera 125 mm, širine 40 mm, nosivosti 350 kg pri 4 km/h (statički 875 kg). Ukupna visina je 192 mm. Cijena je 436.94 KM s PDV-om.

Heavy duty fixed castor, with polyurethane torsion spring, heavy duty wheel, with Blickle Extrathane® polyurethane tread, with aluminium wheel centre, with extra crowned running tread, with s teel thread guard, antistatic

436.94 KM

Cijena s PDV-om. Dostava širom Bosne i Hercegovine.

Veće količine: posebna ponuda na upit, +387 62 924 140, info@mhtrade.co.ba.

Tehnički podaci

Šifra artikla937371
EAN4047526392369
Promjer točka125 mm
Širina točka40 mm
Ukupna visina192 mm
Nosivost pri 4 km/h350 kg
Statička nosivost875 kg
Veličina ploče100 x 85 mm
Razmak rupa65.0 x 55.0 mm
Offset46 mm
Ne ostavlja tragoveda
ESD zaštitada

Nosač

  • solid welded steel construction, solid forged part, zinc-plated, yellow-passivated, Cr6-free
  • patented woodruff key design for outstanding spring-damping properties

Točak

  • tread: high-quality polyurethane elastomer Blickle Extrathane®, hardness 92 Shore A, colour grey, non-marking, non-staining
  • wheel centre: die-cast aluminium, colour silver grey

Dodatne karakteristike

  • high chemical resistance to many aggressive substances
  • operating temperature: -20 °C to +70 °C, temporarily up to +90 °C, reduced load capacity over +40 °C
  • electrical conductivity (ohmic resistance) ≤ 107Ω
